Arduino IoT 物聯網基礎學習套件組

NT$960

Arduino IoT 物聯網基礎學習套件組

此套件組可以實作物聯網或雲端網路實驗,WiFi模組採用 ESP8266(ESP-12F)可以利用本身AT Command與Arduino做溝通,也可以獨立使用WiFi模組。此套件可提供初學者從S4A/S2A或Arduino基礎到物聯網的學習應用,是學習Arduino物聯網基礎應用必備的入門套件組。

分類: 標籤:

描述

商品內容

Arduino UNO R3主控板 1個

S4A感測互動擴充板 V2 1個

LM35溫度感測模組 1個

繼電器模組 1個

WiFi(ESP8266) 模組 1個

USB cable (100cm) 1條

I2C LCD1602 模組(附RJ11轉杜邦線) 1條

RJ11 6P4C 25cm信號線 3條

收納盒 1個

程式範例

/////////////////////////////////

//// 功能: WiFi ESP8266 with S4A Sensor Board v2 Testing

//// 日期: Oct 2016

//// 作者: Dennis

//////////////////////////

#include <SoftwareSerial.h>

#include <Wire.h>
#include <motoLiquidCrystal_I2C.h>

#include “motoESP8266.h”

SoftwareSerial esp8266(3,2); // for S4A Sensor Board v2 or IO Board,

LiquidCrystal_I2C lcd(0x27,16,2); // set the LCD address to 0x27 for a 16 chars and 2 line display

#define AP_SSID “XXXXXXXX” // change this to match your WiFi SSID

#define PASSWORD “XXXXXXXX” // change this to match your WiFi password

ESP8266 wifi(esp8266);

int LED_CONNECT_PIN = 11;

int Relay_Pin = 12; // 繼電器模組 I/O 位置 D12

int analogPin = A3; //LM35接在A3

int readValue = 0;

float temperature = 0;

float temperatureF = 0;

void setup() {

lcd.init(); // initialize the lcd

lcd.backlight();

lcd.print(“Getting IP …”);

// change if necessary to match your modules’ baud rate

esp8266.begin(9600);

Serial.begin(9600);

Serial.println(“begin.”);

wifi.restart();

if (wifi.setOprToStation()) {

Serial.print(“set to STATION mode ok\r\n”);

} else {

Serial.print(“set to STATION mode err\r\n”);

}

wifi.joinAP(AP_SSID, PASSWORD);

delay(8000);

Serial.print(“IP: “);

String ipaddress = wifi.getLocalIP();

Serial.println(ipaddress);

lcd.clear();

lcd.setCursor(0,0);

lcd.print(“IP:”);

lcd.setCursor(0,1);

lcd.print(ipaddress);

pinMode(Relay_Pin, OUTPUT);

}

void loop()

{

digitalWrite(Relay_Pin, HIGH);

delay(5000);

digitalWrite(Relay_Pin, LOW);

delay(5000);

readValue = analogRead(analogPin);

//Serial.println(readValue);

temperature = (readValue * 0.0049);

temperature = temperature * 100;

temperatureF = (temperature * 1.8) + 32;

Serial.print(“Temperature: “);

Serial.print(temperature);

Serial.print(“C \t”);

Serial.print(temperatureF);

Serial.println(“F”);

}
接線範例

LCD 模組 A4A5 孔位

WiFi模組  D2D3 孔位

繼電器  D12D13 孔位

LM35溫度  A3A4 孔位
